Division of Building Materials

Laboratory equipment in the Division of Building Materials

The following is a list of the laboratory equipment available in the Division of Building Materials.



3D hand-held laser scanner

Descritption

3D-Handlaserscanner

The Einscan HX mobile handheld laser scanner enables the digital capture of objects with a resolution of up to 0.05 mm. The scans can then be used to create 3D models for comparing the target/actual geometry of printed objects or reverse engineering, for example.

3D Plastic Printer

Description

3D-Kunststoffdrucker Ultimaker

3D plastic printer with Fused Deposition Modelling (FDM) technology and a build volume of 223 x 220 x 205 mm. Compatible with filament diameters of 2.85 mm.

8-channel ultrasonic measuring system

Description

Ultraschallmessgeraet

The ultrasonic measuring system measures the test specimen's stiffness behaviour as a function of time.

Futher information

Adiabatic and semi-adiabatic concrete calorimeters

Description

Teiladiabatisches Kalorimeter

As many as 3 adiabatic and 4 semi-adiabatic calorimeters are available for determining the temperature increase due to the heat of hydration released during cement hydration.

Further information

Anton Paar MCR 502 Rheometer

Description

Anton Paar Rheometer

The rheometer measures the deformations of the material (e.g. cement suspension) under the influence of the load entered in the shear profile. Rheological properties can be determined from the data obtained.

Further information

CNC Portal Milling Machine

Description

CNC-Fräsmaschine

By means of the CNC portal milling machine (computer numerical control), components made of a wide variety of materials (aluminium, plastic, wood, polystyrene) can be produced with a high degree of precision.

Further Information

Digital Construction Site

Description

Digitale Baustelle

The “Digital Construction Site” stands out as a unique and large-scale research infrastructure, offering an environment to explore digital technologies within authentic construction site conditions. This application-focused and adaptable research facility opens up exceptional new opportunities for investigating the potential of a digital and integrated design and production process. The infrastructure comprises a gantry system featuring a fully-automated mixing plant designed for the 3D printing of 1:1-scale building components. Additionally, it includes a mobile robotic unit for collaborative digital construction processes, along with testing and measurement equipment for on-site material characterization and component analysis. The “Digital Construction Site” is a collaborative effort involving the Institute for Construction Engineering and Management (ibb), the Institute of Geodesy and Photogrammetry (IGP), the Institute of Structural Design (ITE), and the Institute of Building Materials, Concrete Structures and Fire Safety (iBMB).

Digital Microscope VHX-2000D

Description

Digitalmikroskop

The digital microscope acquires composite images in both the depth and the area through transmitted or reflected light.

Further information

ebt-V-Rheometer

Description

ebtV
  • Portable, battery-powered, compact net-independent rheometer for fresh concrete
  • Measurement of the fresh concrete's flow resistance
  • Operation in two different modes:
    • P-mode: for the common or vibrated and stiff concretes
    • V-mode: for modern concretes such as self-compacting or self-consolidating concretes, SCC and UHPC
GOM Aramis/Pontos

Description

GOM

By means of digital image correlation, movements and deformations can be captured optically and thereby contact-free, which allows conclusions to be drawn about e.g. strains, stresses and consequently also material characteristics.

Further information

ICAR Plus Rheometer

Description

ICAR-Plus-Rheometer
  • Portable concrete rheometer
  • Performing two types of rheological measurements
    • Static stress growth
    • Dynamic flow curve: characterization of the basic rheological flow properties of fresh concrete: yield stress and plastic viscosity (Bingham parameters)
  • Maximum possible aggregate grain size to measure: up to 32 mm
Isothermal TAM Air heat flow calorimeter

Description

TAM Air

Isothermal heat flow calorimetry enables a time-resolved investigation of cement hydration. Endothermic or exothermic reactions lead to a temperature change in the sample, which is converted into a heat flow signal.

Climate Test Chamber

Description

Klimaschrank

By means of the climatic test chamber, different environmental conditions (temperature, humidity and carbon dioxide content) can be conveniently simulated.

Further information

Magritek NMR-Mouse

Description

NMR-Mouse

The NMR-MOUSE is a non-destructive sensor that combines the strengths of time-domain NMR with microscopic spatial resolution. Due to its compact size, the system is portable, and the open sensor geometry allows the measurement of spin densities, relaxation times, and self-diffusion coefficients. This allows measurements for monitoring water transport in dynamic processes, such as water absorption or drying in concrete samples.

Mechanical Testing Machines

Description

Würfelpresse

With the existing testing machines, typical mechanical tests can be carried out:

  • Hydraulic compression testing  (for test specimens 15 x 15 x 15 cm3) with 3000 kN
  • Electromechanical tensile/compression testing machine with 500 kN

Further information

MHG blasting system model SMG

Description

MHG-Strahlanlage

With the injector blast cabinet, surfaces can be specifically reworked, e.g. the cleaning off of non-activated particles from printed objects from selective cement activation or the roughening of concrete surfaces for the subsequent application of repair measures. The blasting material used can be reused via a recovery system

Micro-computed tomography (microCT) system

Description

Mikrocomputertomographiesystem

The micro-computed tomography device can be used to non-destructively examine the internal structures of samples made of a wide variety of materials.

Further information

microTrac helium pycnometer

Description

MicroTrac

The microTrac helium pycnometer is a measuring device for material characterisation with regard to volume and density determination. The helium pycnometry method is used to determine the real density of porous solids and powders.

Mobile robot Baubot

Description

Baubot Mobiler Roboter

The Baubot is a fully mobile robot system consisting of a fully electric heavy-duty crawler platform and a 6-axis industrial robot. The Baubot therefore offers a wide range of possible uses.

Particle Track G400 (Mettler Toledo)

Description

FBRM, Particle Track

The Particle Track probe-based instrument with Focussed Beam Reflectance Measurement (FBRM) technology enables continuous analysis of particle size distribution, number and shape. The probe can be used in suspensions with high solids concentration.

Further information

Progress SCA laboratory printer

Description

SCA-Labordrucker

With the particle bed laboratory printer from Progress AG, building components can be additively manufactured with a high degree of freedom of shape using Selective Cement Activation (SCA). Cement hydration is controlled locally by applying water to a particle bed consisting of cement and fine aggregate. The construction box measures 0.7 m x 0.35 m x 0.5 m (l x w x h).

Sliding Pipe Rheometer (SLIPER)

Description

Sliper
  • Portable
  • Investigation of concrete pumpability both in the laboratory and on the construction site
  • Description of the fresh concrete properties and thus forecasts for the planned pumping process
  • Evaluation function in the smartphone
Smart Additive Material Investigator (SAMMI)

Description

SAMMI

SAMMI is a test setup for the field of additive manufacturing with concrete. It was introduced as a small-scale test setup for the Digital Building Fabrication Laboratoy (DBFL).

Further information

Temperature Stress Testing Machine(TSTM)

Description

TSTM

By means of the three temperature stress testing machines (TSTM), hardening materials such as concrete can be subjected to stresses or deformations whilst they are still hardening.

Further information

TOC-L CPN

Description

TOC-Analysator

The TOC analyser measures the total organic carbon content of an aqueous sample.

Further information

UR-10e-Robot

Beschreibung

UR-10e

The UR-10e from Universal Robots is a collaborative robot with a load capacity of 12.5 kg and a reach of 1300 mm. The Cobot offers numerous possible uses such as:

  • Stick
  • Polishing
  • Welding
  • Pick & Place tasks
  • 3D printing of Clay/Concrete
  • and many other possible uses
Viskomat XL - Rheometer for fresh concrete

Description

Rheometer

The rheometer measures the torque absorbed by a measuring probe as a measure of the sample viscosity.

Further information
